FemtoFiber smart 780 PT
Femtosecond fiber laser for handheld devices
Making integration of lasers into handheld devices easy
FemtoFiber smart 780 PT
Femtosecond fiber laser for handheld devices
The FemtoFiber smart 780 PT is a small sized, low weight and low power consuming all fiber-based femtosecond laser system ideally fitting for handheld and/or battery driven inspection devices.
It unites both supply electronics and fiber laser optics in one box, with very compact SHG unit behind a flexible, 2 meters long fiber delivery, being thus one of the smallest fiber laser units on the market.
The system only needs 12 V power supply and comprises a collimated free-beam output at 780 nm.
Your Benefits
2 m fiber delivery to your (handheld) device
Flexible fiber delivery between laser unit and SHG allows easy integration to handheld scanning devices
The fiber laser system provides very short laser pulses at 780nm after the tiny miniature SHG device (20 x 20 x 80mm³). The metal shielded fiber, as well as the small SHG allow to easily integrate the laser into a handheld scanning device, adding just lowest possible weight for the integration device.
Small size, low weight, low power consumption (battery-ready)
Lasers to be integrated into portable devices need to be small in size, low in weight, and especially suited to typical battery-operated environments.
The small form factor of the laser unit plus the lowest possible weight allows to integrate the laser to be integrated in shoe-box sized, compact inspection devices. The low power consumption of les than 20 W allows to use a 12 V battery power supply. Air cooling and a well-suited power management are inevitable to integrate the system into portable devices.
True OEM system, well -proven and turn-key
OEM needs often very specific parameters, system-to-system equality and full performance even under difficult environmental conditions
TOPTICA is equipping OEM systems since more than 20 years, having collected many experiences on the needs of individual integration tasks. Our customers trust TOPTICA!
Options
FemtoFiber smart Switchbox
Adds all necessary functions and features to a full-CDRH/CE-certified system
Specifications
Related Products
Literature
Scientific Publication
-
Handheld multiphoton and pinhole-free reflectance confocal microscopy enables noninvasive, real-time cross-sectional imaging in skin
K. Montgomery, et al., Handheld multiphoton and pinhole-free reflectance confocal microscopy enables noninvasive, real-time cross-sectional imaging in skin; Nature (2024)
