Holography & Augmented Reality
Holography for AR & automotive applications
Shaping light for the next generation of displays and optics
Holography has evolved from an artistic curiosity into a cornerstone technology for next-generation optical systems. From augmented reality (AR) displays and automotive lighting to precision metrology, data storage, and optical security, holography today enables engineers and designers to shape, direct, and control light with unprecedented precision.
At the core of this revolution lies the laser — providing the coherence, wavelength stability, and beam quality necessary to record and reconstruct complex holographic structures.
With modern laser systems offering tailored wavelengths, perfect spatial coherence, and long-term stability, laser-based holography has become the preferred technology for industrial manufacturing of holographic optical elements (HOEs) and functional volume holograms.
The principle: Recording and reconstructing light waves
A hologram is a three-dimensional record of the light field scattered from an object or generated by a computer.
When two coherent laser beams — the object beam and a reference beam — intersect within a photosensitive material, they create an interference pattern that encodes both amplitude and phase information of the wavefront.
After exposure and development, this pattern acts as an optical element that can reconstruct or transform light, performing functions such as focusing, beam splitting, wavelength filtering, or waveguiding.
Depending on the recording material and geometry, holograms can be:
- Surface relief holograms, embossed or replicated for mass production, or
- Volume holograms (HOEs), where the optical information is stored throughout the bulk of the material — offering high diffraction efficiency, wavelength selectivity, and design flexibility.
Industrial holography uses highly coherent laser light to record these structures with nanometer precision, ensuring optical components that perform reliably under real-world conditions.
Application areas of industrial holography
1. Augmented & mixed reality (AR/MR) displays
Volume holographic optical elements (HOE) are key to lightweight, transparent display optics used in AR headsets and smart glasses.
These HOEs function as waveguides, combiners, or lenses, directing images from microdisplays into the user’s eyes while maintaining transparency to the environment.
Holographic recording with multiple wavelengths (typically RGB: 450, 520, 637 nm) allows full-color projection and precise angular or spectral control — essential for compact, bright, and natural-looking AR experiences.
Lasers with excellent coherence length and spectral purity ensure clean interference patterns and uniform waveguide gratings across large apertures in the manufacturing process.
Why lasers with tunable wavelength matching?
Because only coherent sources with precise matching to the RGB requirements (and correction for the shrinking during processing) can encode phase information with the precise color registration and minimal optical aberration.
2. Automotive lighting & sensors
Holographic elements are now used in head-up displays (HUDs), adaptive headlights, and LIDAR beam steering.
In HUDs, volume holograms combine and project information directly onto the windshield, reducing optical complexity and enabling wide fields of view.
In lighting systems, holographic diffusers and lenses control beam shape and color without bulky optics.
For LIDAR and sensing, holographic gratings allow precise beam shaping and scanning for object detection and depth measurement — without moving parts.
Laser-based holography ensures that these components meet automotive demands for temperature stability, optical robustness, and reproducibility, far beyond what is achievable with conventional diffractive optics.
3. Data storage
Holographic data storage records information throughout the volume of a photosensitive medium, not just on its surface.
Using coherent laser beams, multiple data pages can be stored and retrieved at different angles or wavelengths — enabling terabyte-scale capacity and rapid access times.
Lasers with narrow linewidths, precise wavelength control, and long coherence lengths (on the order of tens of meters) are required to achieve stable and high-density recordings. 405 nm has become a wavelength of choice for this application due to the high data storage, which can be achieved and the compatibility to existing Blue-Ray laser diode technology in the readout process.
4. Metrology & non-destructive testing
Holographic interferometry is widely used in precision metrology to measure surface deformation, stress, vibration, and refractive index changes in materials and devices.
By comparing phase differences between reference and test holograms, engineers can visualize microscopic changes — even at the nanometer or sub-nanometer scale.
Such measurements are invaluable in semiconductor inspection, MEMS characterization, and aerospace materials testing.
5. Security & authentication
From banknotes and passports to brand protection and product packaging, holograms remain the most visually striking and tamper-proof optical security feature.
Unlike mechanically embossed or printed patterns, laser-written holograms encode true 3D optical information, making them virtually impossible to counterfeit.
Modern systems use computer-generated holography (CGH) and multi-wavelength recording to embed encrypted optical signatures — only readable with specific illumination conditions.
6. Art, architecture & education
Laser-generated holograms are also used to create realistic 3D visualizations, museum exhibits, and architectural installations, combining technology and creativity.
Volume holograms can reproduce spatial light fields with natural depth cues and parallax, allowing viewers to “walk around” an image without special glasses.
In educational settings, holography helps visualize wave optics, quantum effects, and 3D spatial relationships — turning abstract concepts into tangible experiences.
Laser requirements for industrial holography
Industrial holography depends entirely on the quality of the recording laser.
To record clean, high-contrast interference patterns, the laser must provide:
- Long coherence length (tens of meters or longer) for stable interference over large recording geometries.
- Narrow linewidth (MHz range) to prevent reduction of contrast ratio during exposure.
- Excellent beam quality (TEM₀₀) for uniform illumination.
- High pointing and power stability for reproducible hologram recording.
- Selectable wavelengths depending on the holographic medium and final application.
A simple rule: 1 MHz of linewidth corresponds to 100 m of coherence length (physically precise: 95 Meters with Lorentzian line profile - independent of the wavelength!). The chosen coherence length should always be substantially larger than the largest beam path difference in the recording setup.
Typical laser types and wavelengths
| Application / Method | Preferred Laser Wavelengths | Power Range | Key Laser Features |
| AR/MR display holography | RGB: 445-460, 515-532, 630-640 nm | 50 - 3000 mW per color | Narrow linewidth, wavelength tunability |
| Volume hologram mastering | UV 406 nm or 411 nm | 100 - 2000 mW | Short wavelength for high spatial resolution |
| Security & CGH recording | 532 nm, 633 nm | 100 - 200 mW | Long coherence length, low noise, single-mode operation |
| Holographic Interferometry | 633 nm, 532 nm | 10 - 10000 mW | Robust operation |
Lasers such as single-frequency diode and fiber lasers offer the right combination of stability, tunability, and compactness for industrial holography setups. Fiber lasers and frequency-doubling lasers can reach the higher power range with otherwise comparable performance.
Modern systems can integrate multiple selectable wavelengths in one laser engine, enabling flexible recording of multi-color or multiplexed holograms from a single source.
Laser-generated volume HOEs vs. mechanically printed holograms
While mechanically embossed holograms are ideal for mass replication of simple diffractive effects, laser-recorded volume holographic optical elements offer distinct advantages:
| Laser-Generated HOEs | Mechanically Printed Holograms |
|---|---|
| Wavelength and angle selectivity | Broad, uncontrolled spectral response |
| True 3D optical phase encoding | 2D surface relief only |
| Precise, repeatable fabrication | Less control over optical properties |
| High diffraction efficiency | Limited brightness and color fidelity |
| Custom optical functionality (focus, combine, filter) | Static decorative appearance |
This makes laser-generated HOEs the technology of choice for functional optics — not just for visual effects, but as engineered optical components driving innovation in display and sensing technologies.
Paving the way to the next generation
Laser-generated holograms are now pioneering the optics of tomorrow.
- In AR headsets, holographic combiners enable sleek, lightweight displays with immersive realism.
- In automotive systems, HOEs integrate HUDs and sensor optics directly into windshields and headlights.
- In optical communication and quantum computing, holographic beam shapers and multiplexers guide information at light speed.
- And in metrology and testing, holography provides non-destructive insights into structures invisible to conventional optics.
As researchers and engineers push optical design toward higher performance and smaller form factors, laser-based holography stands as the key enabling technology — offering unmatched flexibility, precision, and scalability.
Light that designs the future
With coherent, wavelength-stable lasers spanning the visible and ultraviolet spectrum — including custom wavelengths such as 406 or 411 nm for high-resolution recording — TOPTICA’s laser platforms provide the precision, tunability, and stability needed for industrial holography.
